M20 Quick Lock T Ttype Three Head waterproof connector 2Pins

CB-M20-FTF01-20

* M20 Quick Lock T type Three Head waterproof connector 2Pins
* T type Three Head waterproof connector
* Insertion life:1000 times
* Operating temperature:-40℃-105℃
* Outdoor UV resistance: Pass
* Contacts: 2 pin
* Plastic: PA66 Nylon
* Metal: Gilded brass
* Voltage: 300V
* Rated Current: 24A
* Cable Jacket OD: 5.0-9mm,9-12mm
* Wire Installation: Quick Lock
* Certificate: ISO/CE/ROHS/PSE/ETL
* Shipping Port: Shenzhen China
* Payment Terms: T/T bank, Paypal

Quantity:

Contact Now

M20 Quick Lock T Ttype Three Head waterproof connector 2PinsSpecification

This M20 waterproof quick disconnect wire connectors is perfect for use in a range of applications where a reliable waterproof connection is required. waterproof quick disconnect wire connectors features a quick lock design that enables easy and fast connection and disconnection. It also has three heads, which provide additional convenience and versatility when connecting multiple devices. This waterproof quick disconnect wire connectors is built to withstand harsh environments, making it ideal for use in outdoor applications such as marine, automotive, and industrial settings. With its durable construction and reliable performance, this connector is sure to solve many connectivity issues for users.

M20 Quick Lock T type Three Head waterproof quick disconnect wire connectors Parameter Description

Numbers of Poles	2 Pins
Rated Voltage	450V
Rated Current	24A
Wire Section	0.5-2.5mm2
Out Cable Diameter	5-9mm, 9-12mm
Temperature Range	-40℃- 105℃
IP Code	IP68
Housing Materials	PA66

M20 Quick Lock T type Three Head waterproof connector 2Pins Parameter Description
