LP12 Series 8Pin IP68 Waterproof Connector 3A Signal Power Solder Type

EW-LP12S-0825BMB07
Shell material: PBT high performance engineering plastic.
Protection grade: IP68(2m/2h) Rated current:3A Rated voltage :100VAC
Resistant voltage :1500VAC Flame retardant grade: UL94 V-0
Applicable wire gauge: 0.34-0.75mm²/22-20AWG
Operating temperature: -40-+80℃
Meet the certification standard: ETL/SAA/ROHS
Plug life: ≥1900 times The number of cores: 8p
Quantity:
Contact Now

LP12 Series 8Pin IP68 Waterproof Connector  3A Signal Power Solder Type

The LP12 Series stands as a high-performance solution among waterproof electrical connectors, engineered for demanding applications. With an IP68 rating (submersible up to 2 meters for 2 hours), it guarantees exceptional performance in wet, dusty, or harsh industrial environments. These robust waterproof electrical connectors feature a PBT plastic shell, offering superior mechanical strength and chemical resistance, complemented by a UL94 V-0 flame-retardant rating for enhanced safety.

Designed for 3A current and 100VAC, this 8-pin connector is ideal for complex signal and low-power transmission. It supports 22-20AWG cables and features a solder termination for secure, reliable connections. With an operating temperature range of -40°C to +80°C, a mechanical life exceeding 1900 mating cycles, and compliance with ETL, SAA, and RoHS standards, the LP12 ensures long-term durability and global market acceptance. It is the definitive choice for reliable outdoor and industrial connectivity.

LP12 Series 8Pin IP68 Waterproof Connector  3A Signal Power Solder Type drawing

LP12 Series 8Pin IP68 Waterproof Connector  3A Signal Power Solder Type Datasheet

Shell material: PBT high performance engineering plastic.Protection grade: IP68(2m/2h) Rated current: 3A  Rated voltage :100VAC
Resistant voltage :1500VACFlame retardant grade: UL94 V-0Applicable wire gauge: 0.34-0.75mm²/22-20AWG Operating temperature: -40-+80℃
Meet the certification standard: ETL/SAA/ROHS Plug life: ≥1900 times    The number of cores: 2P/3P/5P/6P/7P/8P
